MEMS 3 Channel Signal Conditioner - DCM-03
Features
- OLED display
- 3 channels
- Accuracy better than 0.5>#/li###
- Mains powered
- Wide frequency band and low noise
- User selectable gains
- Adjustable low pass filter
- Output overload indicator. When output is larger than 10V+1V the indication will be on
Applications
- Constant Gravity Measurements
- General Vibration Measurement
- Seismic Vibration Measurement
- Crash Testing
- Auto/Aero Structural Body Surveys
The DCM-03 MEMS DC signal conditioner is for use with DJB’s range of AM, AMB and AMT variable capacitance MEMS accelerometers. The unit has 3 channels and can be used with three single axis capacitive accelerometers or one triaxial capacitive accelerometer. Offering a wide range of features in a compact and powerful unit the DCM-03 is the perfect addition to your low frequency testing system.
For use with the following DJB MEMS Products:
- AM/2.1000 Monoaxial, ±2g, 1000mV/g
- AM/2HR.1000 High Res. monoaxial ±2g, 1000mV/g
- AM/5.300 Monoaxial, ±5g, 300mV/g
- AM/10HR.200 High Res. monoaxial ±10g, 200mV/g
- AM/20.100 Monoaxial, ±20g, 100mV/g
- AM/50HR.40 High Res. monoaxial ±50g, 40mV/g
- AMB/2.1000 Biaxial, ±2g, 1000mV/g
- AMB/2HR.1000 High Res. biaxial ±2g, 1000mV/g
- AMB/5.300 Biaxial, ±5g, 300mV/g
- AMB/10HR.200 High Res. biaxial ±10g, 200mV/g
- AMB/20.100 Bi axis MEMS, ±20g, 100mV/g
- AMB/50HR.40 High Res. biaxial ±50g, 40mV/g
- AMT/2.1000 Triaxial, ±2g, 1000mV/g
- AMT/2HR.1000 High Res. triaxial ±2g, 1000mV/g
- AMT/5.300 Triaxial, ±5g, 300mV/g
- AMT/10HR.200 High Res. triaxial ±10g, 200mV/g
- AMT/20.100 Triaxial, ±20g, 100mV/g
- AMT/50HR.40 High Res. triaxial ±50g, 40mV/g
